Resistor Networks
-
Resistor Network 8-Commoned 100k
Thick film resistor network housed in single in line, low profile packages coated with a special epoxy resin. Metal glaze elements on a ceramic substrate. Power rating (per resistor)- 0.125W Tolerance +/- 2% Pitch 2.54mm (0.1") Temperature coefficient: ±100ppm/°C Max.working voltage: 100V Operating temperature range: –55°C to +125°C Height 5.2mm Width 2.5mm Pitch 2.54 No of pins 9 Length max 22.9
£0.13
-
Resistor Network 8-Commoned 10k
Thick film resistor network housed in single in line, low profile packages coated with a special epoxy resin. Metal glaze elements on a ceramic substrate. Power rating (per resistor)- 0.125W Tolerance +/- 2% Pitch 2.54mm (0.1") Temperature coefficient: ±100ppm/°C Max.working voltage: 100V Operating temperature range: –55°C to +125°C Height 5.2mm Width 2.5mm Pitch 2.54 No of pins 9 Length max 22.9
£0.18
-
Resistor Network 8-Commoned 1k
Thick film resistor network housed in single in line, low profile packages coated with a special epoxy resin. Metal glaze elements on a ceramic substrate. Power rating (per resistor)- 0.125W Tolerance +/- 2% Pitch 2.54mm (0.1") Temperature coefficient: ±100ppm/°C Max.working voltage: 100V Operating temperature range: –55°C to +125°C Height 5.2mm Width 2.5mm Pitch 2.54 No of pins 9 Length max 22.9
£0.18
